60W Desktop Type YL60

Item Code:YL60 Features:

Rated Power: 60W
Input: 100-240V AC, 50 / 60Hz
Protection: Short Circuit, OCP, OVP
Output: 5-36V
Inrush Current: 65 Amps max. at 230VAC/50Hz, full load

Description
Details

Linear power adapter	Desktop type
Model：	YL60
Rated Power:	60W
Input：	100-120VAC 60Hz or 220-240 VAC 50Hz
Output Voltage:	5-36VDC
Output Current:	1.6-4.5A
Input current:	1A max.or 0.5A max
Inrush Current:	65 Amps max. at 230VAC/50Hz,full load
Leakage Current:	0.25mA Max. at 264VAC input
No Load Power Consumption ：	＜ 1.5W
Protections：	Short Circuit /Over Current /Over Voltage
Short Circuit Protection (SCP)：	Protection to Zero Voltage
Over Voltage Protection (OVP):	≤Vout*150%
Over Current Protection (OCP):	110%-180%
Working TEMP.:	-20°C-50°C
Working Humidity：	5%-90% RH non-condensing
Storage TEMP.,Humidity and altitude:	40℃ ~+70°C ambient temperature and a 5% to 95% relative humidity range throughout an altitude range of -60 meters to +5000 meters AMSL.
Input Plug:	EU,US,UK,AU etc. type according to customer's choice
Certificates and approvals:	GS,CE,EMC,SAA,FCC,CB,PSE,CCC,RoHS,REACH
EMI EMISSION:	Radiation Test&Conduction Test: EN 55022/FCC Part 15 Harmonic Test : EN 61000-3-2 Flicker Test : EN 61000-3-3
EMS IMMUNITY:	ESD Test:EN 61000-4-2 RS Test:EN 61000-4-3 EFT Test:EN 61000-4-4 Surge Test:EN 61000-4-5 CS Test:EN 61000-4-6 DIP Test:EN 61000-4-11
MTBF:	100000 hours minimum at full load at 25 C ambient
Life:	3-5 years alternative
Dimension:	1299267mm
Weight:	1150g
Packing:	10PCS/CTN,503912.5cm

Model:	YL60-0504500	YL60-0903500	YL60-1503100	YL60-1903000	YL60-2402500	YL60-3601600
DC Voltage:	5V	9V	15V	19V	24V	36V
Rated Current:	4.5A	3.5A	3.1A	3A	2.5A	1.6A
Current Range:	0-4.5A	0-3.5A	0-3.1A	0-3A	0-2.5A	0-1.6A
Rated Power:	22.5W	31.5W	46.5W	57W	60W	57.6W
Ripple & Noise(max.):	50mVp-p	90mVp-p	150mVp-p	190mVp-p	240mVp-p	360mVp-p
Voltage Tolerance:	±5%	±5%	±5%	±5%	±5%	±5%
Line Regulation:	±3%	±3%	±3%	±3%	±3%	±3%
Load Regulation:	±5%	±5%	±5%	±5%	±5%	±5%
Setup,Rise,Hold up time:	3 second max./40 MS max./5 MS max. at 100VAC input and output max. load.
