Dimming LED Power Supply

- Input voltage: 220-240V/100-120V
- Input Frequency: 50/60Hz
- Dimming with leading edge and trailing edge
- Smooth dimming compatible with most dimmers
- Dimming range 1-100%
- Safety standard: EN61347-1, EN61347-2, UL8750+1310
- EMI standard: EN55015
- EMS standard: EN61547
- Harmonic: EN61000-3-2
- Directive 2009/125/EC
- ERP: EU2019/2020
- Short Circuit, over current and over voltage protection
- Over temperature Protection
- 100% full load burn in test
- Auto restart after remove of fault conditions
- RoHS Compliance

Description
Details

Triac Dimming

Constant Voltage

Model	Power (max.)	Input Voltage	Output Voltage	Output Current(max.)	PF	Voltage Tolerance	Efficiency	Dimension(LxWxH)
YSL100-D	60W	230V/120V AC	12V	5A	≥0.9	±5%	85%	180x66x32mm
YSL100-D	60W	230V/120V AC	24V	2.5A	≥0.9	±5%	85%	180x66x32mm

Constant Current

Model	Power (max.)	Input Voltage	Output Current	Output Voltage (max.)	PF	Voltage Tolerance	Efficiency	Dimension(LxWxH)
YSL100-D	55W	230V/120V AC	1050mA	52V	≥0.9	±5%	85%	180x66x32mm
YSL100-D	55W	230V/120V AC	1400mA	39V	≥0.9	±5%	85%	180x66x32mm
YSL100-D	55W	230V/120V AC	1500mA	36V	≥0.9	±5%	85%	180x66x32mm

0-10V Dimming

Constant Voltage

Model	Power (max.)	Input Voltage	Output Voltage	Output Current(max.)	PF	Voltage Tolerance	Efficiency	Dimension(LxWxH)
YSL100-D	100W	230V/120V AC	12V	6A	≥0.9	±5%	85%	180x66x32mm
YSL100-D	100W	230V/120V AC	24V	3A	≥0.9	±5%	85%	180x66x32mm

Constant Current

Model	Power (max.)	Input Voltage	Output Current	Output Voltage (max.)	PF	Voltage Tolerance	Efficiency	Dimension(LxWxH)
YSL100-D	100W	230V/120V AC	1400mA	71V	≥0.9	±5%	85%	180x66x32mm
YSL100-D	100W	230V/120V AC	2100mA	47V	≥0.9	±5%	85%	180x66x32mm
YSL100-D	100W	230V/120V AC	2400mA	41V	≥0.9	±5%	85%	180x66x32mm
