Matched Battery Type：

Lithium Battery/Lead Acid Battery/Lifepo4 Lithium BatteryL

Charging Mode：

CC/CV/Mode

Input

Range of Input Voltage:

100-250VAC

Input Frequency:

47~63Hz

AC Current:

10A/230V

Leakage Current:

＜1.5mA/240VAC

Efficiency:

≥89.0%

Output

Rated Power:

600W

800W

1000W

Rated Voltage:

54.6V

54.6V

54.6V

Rated Current:

11A

15A

20A

DC Voltage Range:

10V～60V（The maximum output voltage is adjustable by RS485/CAN：32V～60V）

Standby Power：

≤10W

Voltage Tolerance:

±1.0%

Ripple & Noise (Max.)：

≤600mVp-p

Switch Overshoot:

≤10%

LED Indicator：

Green LED ON 250mA（Customizable digital display for voltage）

Setup, Rise, Hold up time:

3s, 40ms, 10ms at 115Vac Full Load

DC connector:

Junbo straight plug, part number 1-01-03-2-0005; paired with socket ELE00011263AA (Vinfast)

Note: Equip according to the actual scenario

ENVIRON MENTAL

Operating Temperature:

-20 ~ +70 (Refer to "Derating Curve")

Storage Temp:

-40℃ ~ 80℃

Storage Humidity:

10 ~ 95% RH

IP:

IP20

Fire rating:

UL94-V0 flame retardant grade, fully meeting compliance requirements

Working Humidity:

20 ~ 95% RH Non-Condensing

PROTECTI ON

Over Load：

105% -150% Rated Output Power

Protection Type: Hiccup Mode,

Over Voltage:

105% -130% Rated Output Power

Protection Type: Shut Down o/p Voltage, Re-power on to recover

Short Circuit:

Shut Down o/p Voltage, Re-power on to Recover

Battery Protection:

Battery Positive and Negative Electrode Protection

DC Output Anti-Spark:

YES,Auto Resume.

SAFETY & EMC

Safety Regulations:

UL1012, IEC/BS/EN61558-1，IEC/BS/EN60335-2-29，IEC/BS/EN60335-1

Withstand Voltage:

I/P-O/P:3KVAC

Isolation Resistance:

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

EMC Emission:

Compliance to EN55032 (CISPR32)

EMC Immunity:

IEC/EN61000-4-2,3,4,5,6,8,11

OTHER

MTBF:

200Khrs min. MIL-HDBK-217F(25℃)

Size:

231*98*55mm

Weight:

3kg / pcs

Packaging:

12PCS/CTN
