MODEL DETAIL SPEC.

YS1000C-

29435000

YS1000C-

42025000

YS1000C-

54620000

YS1000C-

58818000

YS1000C-

67215000

Matched Battery Type:

Lithium Battery/Lead Acid Battery/Lifepo4 Lithium Battery

Charging Mode:

CC/CV/Mode

INPUT

Range of Input Voltage:

100-240VAC

Input Frequency:

47~63Hz

Inrush Current:

Cold Start 80A/230V

AC Current:

10A/230V

Leakage Current:

< 1.5mA/240VAC

Efficiency:

89.0%

89.5%

90%

90.5%

91.0%

OUTPUT

DC Voltage:

29.4V

42V

54.6V

58.8V

67.2V

Rated Current:

35A

25A

20A

18A

15A

Rated Power:

1029W

1050W

1092W

1058.4W

1008W

Standby Power:

≤ 10W

Voltage Tolerance:

± 1.0%

Ripple & Noise (Max.):

≤600mVp-p

Switch Overshoot:

≤ 10%

LED Indicator:

Green LED ON <100mA, Red LED ON> 250mA

Setup, Rise, Hold up time:

3s, 40ms, 10ms at 115Vac Full Load

ENVIRON

MENTAL

Operating Temperature:

-20 ~ +70 (Refer to "Derating Curve")

Storage Temp:

-40℃ ~ 80℃

Storage Humidity:

10 ~ 95% RH

Working Humidity:

20 ~ 95% RH Non-Condensing

PROTECTION

Over Load:

105% -150% Rated Output Power

Protection Type: Hiccup Mode,

Over Voltage:

105%–130% Rated Output Power

Protection Type: Shut Down o/p Voltage, Re-power on to recover

Short Circuit :

Shut Down o/p Voltage, Re-power on to Recover

Battery Protection:

Battery Positive and Negative Electrode Protection

DC Output Anti-Spark:

YES, Auto Resume.

SAFETY

&  EMC

Safety Regulations:

UL1012, IEC/BS/EN61558-1 ， IEC/BS/EN60335-2-29 ， IEC/BS/EN60335-1

Withstand Voltage:

I/P-O/P:3KVAC

Isolation Resistance:

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC / 25℃/ 70% RH

EMC Emission:

Compliance to EN55032 (CISPR32)

EMC Immunity:

IEC/EN61000-4-2,3,4,5,6,8,11

OTHER

MTBF:

200Khrs min. MIL-HDBK-217F (25℃)

Size:

231*98*55mm

Weight:

3 kg / pcs

Packaging:

12 PCS/CTN
